M300F-A Multi-parameter Analyzer
Multi-reading feature allows auto-read,timed-read and continuous-read.
GENERAL FEATURES
●High resolution LCD display,5.7 inches.
●Multi-reading feature allows auto-read,timed-read and continuous-read.
●Automatic/Manual temperature compensation ensures accurate results.
●Auto-hold feature senses and locks the measurement endpoint.
●Data Storage 500 sets(GLP-compliant).
●Support for USB or RS-232 communication.
●Reset feature automatically resumes all settings back to factory default options.
●IP54 waterproof.
pH
●1-5 points calibration with Standard Recognition.
●Selectable pH buffer groups,including NIST,DIN,GB,USA.
●Automatic electrode diagnosis with pH slope and offset display.
Ion
●1-5 points calibration.
●Selectable measurement unit,includingμg/L,mg/L,g/L,mmol/L,pX,ppm,ppb,etc.
●Multi-measurement modes are supported,including Direct Reading mode,Standard Addition mode,Sample Addition mode and GRAN mode.
●Over 10 methods are built-in,including F-,Cl-,Br-,I-,NO3-,BF4-,NH4+,K+,Na+,Ca2+,Cu2+,Pb2+,Ag+and etc.,user-defined method is supported.
Conductivity
●1-3 points calibration with Standard Recognition.
●Settable parameters,including cell constant,temperature compensation coefficient and TDS factor.
●Temperature compensation type(none,linear,pure water).
DO
●Support for air-saturated water or zero oxygen calibration.
●Auto barometric pressure compensation
●Manual Salinity Factor Correction
●Selectable pressure unit,including kPa,mbar,Torr,Atm.
| Model | M300F-A | |
| Parameters | pH/EC/ISE/DO/Temp. (mV/ORP/pX/Resistivity/TDS/Sal./DO Saturation)
|
|
|
pH |
Range | -2.000 to 20.000 pH |
| Resolution | 0.1, 0.01pH | |
| Accuracy | ± 0.001 pH | |
| Calibration Points | Up to 5 | |
| Standard Customization | Yes | |
| Standard Recognition | NIST, GB, USA and DIN buffers | |
| Slope Limit | Yes | |
|
mV/ORP |
Range | -2000.00 to 2000.00 mV |
| Resolution | 0.1mV | |
| Accuracy | ± 0.3 mV or ± 0.1% | |
|
pX |
Range | -2.000 to 20.000 pX |
| Resolution | 0.1, 0.01pX | |
| Accuracy | ± 0.001 pX | |
| Calibration Points | Up to 5 | |
|
ISE |
Range | 1.000e-9 to 9.999e+9 |
| Units | mol/L, mmol/L, g/L, mg/L, μ g/L, ppm, ppb | |
| Resolution | Up to 4 significant digits | |
| Accuracy | ± 0.5% | |
| Calibration Points | Up to 5 | |
| Conductivity | Range | 0.000 μ S/cm to 1000 mS/cm |
| Resolution | 0.001 μ S/cm minimum, various with range selection | |
| Accuracy | ± 0.1% FS | |
| Reference Temperature | 20, 25 ºC | |
| Calibration Points | Up to 3 | |
| Standard Recognition | 84 μ S/cm, 1413 μ S/cm, 12.88mS/cm | |
| Resistivity | Range | 5.00 Ω ·cm~20.0 M Ω ·cm |
| Resolution | 0.01 Ω ·cm minimum | |
| Accuracy | ± 0.1% FS | |
| TDS | Range | 0.000~300 ppt |
| Resolution | 0.001 ppm minimum, changed with range | |
| Accuracy | ± 0.1% FS | |
|
Salinity |
Range | 0.0 ～ 80.0 ppt |
| Resolution | 0.1ppt | |
| Accuracy | ± 2ppt | |
|
Temperature |
Range | -5 to 110 ºC, 23 to 230 ºF |
| Unit | ºC, ºF | |
| Resolution | 0.1 | |
| Accuracy | ± 0.2 | |
| Measurement | Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts | Reading, Stable, Locked | |
| Temp. Compensation | ATC, MTC | |
| Data management | Data Storage | 500 results each |
| GLP Features | Yes | |
| Inputs | pH Electrode | BNC(Q9) |
| DO with Temp. Probe | 4-pin aviation connector | |
| Conductivity with Temp. Probe | 5-pin aviation connector | |
| Outputs | USB | PC |
| RS 232 | printer | |
|
Display options |
Backlight | Yes |
| Auto Shutdown | 1~60 min, off | |
| IP Rating | IP54 | |
| Date and Time | Yes | |
| General | Power | AC Adapter, 100-240V AC input, DC9V output |
| Dimensions | 242 × 195 × 68 mm | |
| Weight | 900g (1.98 lb) | |
